Axel Technology FX RDS | Audio Processors | Radio Studio

Digital RDS/RBDS encoder option for Falcon X. Dynamic
services generation: 60 PS programmable messages for
each DataSet. 2 interchangeable DataSet via remote control.
RadioText, Alternative Frequency AF, Traffic Program TP,
Traffic Announcement TA, EON, M/S, CT, PI, PTY, PIN. UECP
SPB490 compliant.

Dante™ option (also supporting AES67 and SMPTE ST 2110-30 transport protocols) provides an Ethernet connection for 2 Stereo Input and 2 Stereo Output, with independent and dedicated Level Control and Sample Rate Conversion.

System Features
Remote interface GPIn 6x GP In optocoupled
Remote interface GPOut 4x Relays – dry contacts
Remote interface connector DB 25 female connector - EMI suppressed
Remote interface GPIO Voltage and Current DC 5V Source and Sink 10 mA
Communication Port 2 x RS232, 3 x USB, 1 x LAN
Serial Interfaces 1st RS232 on DB9 female connector - EMI suppressed
2nd RS232 on DB25 female connector - EMI suppressed
Firmware can be upgraded in the field Yes
Front-panel Colour TFT Display No (Falcon X6) / Yes (Falcon X5, X7, D7 and Fox 3)
Data may be entered on-site with Front-panel Buttons No (Falcon X6) / Yes (Falcon X5, X7, D7 and Fox 3)
Front Panel LEDs 40
