DAC-70 - DatavideoEAN  672255004326

Converters > Digital > Analog
EAN:672255004326
₦ 1.155.731,43
VAT Included
Adcom - Datavideo
New
Available in 14 days
QUOTE
BUY
Datavideo HD/SD-SDI to VGA converter. It's designed for use with equipment such as projectors, plasma TV, and LCD screens.
VGA-HDMI-SDI to SDI Converter
Features
Up / Down / Cross Converter

Features
3G/HD/SD Up/Down/Cross convert
Audio/HDMI/SDI/VGA input
3G/HD/SD SDI and HDMI output
Can be rackmounted using optional RMK-2 2RU Rack solution
DC 12V, 3.6 watts
Video Input formats
SD-SDI: 525i, 625i
3G-SDI: 1080p60/50, 1080p59.94 (Level A)
HD-SDI: 1080i60/50, 1080p30/25/24, 1080p29.97, 1080p23.98, 1080i59.94, 720p60/50, 720p59.94
HDMI: (YUV/RGB): 1080p60/50, 1080p59.94, 1080p30/25/24, 1080p29.97, 1080p23.98, 1080i60/50, 1080i59.94, 720p59.94, 720p60/50, 576p, 480p, VGA, 1600x1200@60Hz, 1400x1050@60Hz, 1366x768@60Hz, 1280x1024@60Hz, 1024x768@60Hz, 800x600@60Hz

Video Output formats
SDI / HDMI (YUV: 4:2:2): 1080p60/50, 1080p59.94, 1080p23.98/29.97/24/25/30, 1080i60/50, 1080i59.94, 720P60/50, 720P59.94, 525i, 625i

Supported Audio formats
SDI embedded Audio: Up to 8-CH, PCM 48KHz
HDMI embedded Audio: up to 8-CH, PCM 96KHz
- Stereo audio input: 2-CH, PCM 48KHz

* USB interface for firmware upgrade
